TSM, Inc. - DOUBLER2 - 4 Valves on One Wire / Expand or Repair Your Irrigation System with Ease

TSM, Inc. - DOUBLER2 - 4 Valves on One Wire / Expand or Repair Your Irrigation System with Ease

DOUBLER Doubler allows independent control of four automatic valves with only one valve wire and the common. When Doubler2 is connected to one station of the controller, it switches when the station is turned on and passes the electrical current to the first valve. The next time that station is turned on, Doubler switches to the next valve. It simply alternates between the valves. If four stations are connected to Doubler by a jumper wire in the controller, it switches between the four valves corresponding to the four stations. Each valve will water for as long as the time set on the controller.

Input 24 VAC
Output 24 VAC
Operations Rated greater than 30,000,000 operations
Nominal Power 33ma
Switch Time 7ms
Wire Size 18 Gauge
Unit Size 4" H x 2.7" Dia
Waterproof Yes
Install Distance Can be installed any distance from the controller
$226.03
TSM, Inc. - DOUBLER2 - 4 Valves on One Wire / Expand or Repair Your Irrigation System with Ease—
$226.03

Product Information

Shipping & Returns

Description

DOUBLER Doubler allows independent control of four automatic valves with only one valve wire and the common. When Doubler2 is connected to one station of the controller, it switches when the station is turned on and passes the electrical current to the first valve. The next time that station is turned on, Doubler switches to the next valve. It simply alternates between the valves. If four stations are connected to Doubler by a jumper wire in the controller, it switches between the four valves corresponding to the four stations. Each valve will water for as long as the time set on the controller.

Input 24 VAC
Output 24 VAC
Operations Rated greater than 30,000,000 operations
Nominal Power 33ma
Switch Time 7ms
Wire Size 18 Gauge
Unit Size 4" H x 2.7" Dia
Waterproof Yes
Install Distance Can be installed any distance from the controller
