Rain Bird 100DV DV Series 1" Inline Irrigation Valve
Rain Bird 100DV Irrigation Valve
Meet the Rain Bird 100DV Series 1" Valve, the industry-leading choice for residential irrigation systems that professionals have trusted for decades. This valve is the workhorse of the Rain Bird lineup, engineered for one thing: long-lasting, reliable performance. Its robust construction and balanced-pressure diaphragm ensure a long life and consistent operation, giving you peace of mind and letting you spend more time enjoying your landscape.
The 100DV valve is built to handle tough conditions with a double-filtered pilot-flow design that resists clogging and grit, ensuring it works flawlessly even with dirty water. Maintenance and installation are a breeze, thanks to its user-friendly features. It includes an external bleed to manually flush out debris during start-up and an internal bleed for spray-free manual operation. The 100DV features a 1-inch inlet and outlet and is compatible with all standard 24 VAC irrigation timers, making it the perfect, dependable heart for your sprinkler system.
*One Solenoid Handle Per Order
Features:
- Double-filtered pilot-flow design for maximum reliability.
- Balanced-pressure diaphragm for long life.
- External bleed to manually flush system of dirt and debris during installation and system start-up.
- Internal bleed for spray-free manual operation.
- Energy-efficient, low-power encapsulated solenoid with captured plunger and 90-mesh (200 micron) solenoid filter.
- Buna-N diaphragm with self-cleaning 90 mesh (200 micron) pilot water filter and captive spring.
- Operates in low-flow and Xerigation® applications when the RBY filter is installed upstream.
- 1.25" (3,2 cm) stainless steel phillips head screws.
- Accepts latching solenoid for use with Rain Bird battery-operated controllers.
Specifications:
- Pressure: 15 to 150 psi (1,0 to 10,4 bar)
- Flow Rate: 0.2 to 40 GPM (0,05 to 9,08 m3/h; 0,01 to 2,52 l/s). For flows below 3 GPM (0,75 m3/h; 0,21 l/s) or any Xerigation® application, use RBY-100-200MX Filter installed upstream.
- Temperature: Up to 110° F (43° C)
- Ambient air temperature: Up to 125° F (52° C)
- 24 VAC 50/60 Hz (cycles per second) solenoid power requirement
- 0.30 A (7.2 VA) inrush current; 0.23 A (5.5 VA) holding current
- Solenoid coil resistance: 38 Ohms
- Inlet Size: 1
- Flow Control: 0.2 - 40
- Pressure Rating/Range: 15 - 150
Dimensions:
- Height: 4 1/2" (11,4 cm)
- Width: 3 1/3" (8,4 cm)
- Length: 4 3/8" (11,1 cm)
