Add with the following Indoor Unit:

HAIER AW24TE2VHA TEMPO SERIES SINGLE ZONE INDOOR HIGHWALL UNIT 24000 BTU 230V

Great introduction into using ductless AC systems.

If you're new to ductless mini split air conditioner systems, the Tempo series makes a great introductory option for single room heating and cooling. Our Tempo mini split AC series is budget friendly and great for providing consistent heating and cooling in milder climates.

Features:

• DC Inverters
• Turbo Mode
• Blue Fin
• Quiet Mode
• Easy to install
• Easy PCB replacement

Cooling:

• Rated Capacity BTU/hr: 24,000
• Capacity Range Btu/hr: 6,500~26,000
• Rated Power Input W: 2,150
• SEER: 16
• EER: 10.0
• Moisture Removal Pt./h: 5.9

Heating:

• Heating Capacity Range Btu/hr: 6,800~28,000
• Rated Heating Capacity 47F BTU/hr: 26,000
• COP: 3.22
• Rated Heating Capacity 17°F Btu/hr: 16,600
• Max. Heating Capacity 17°F Btu/hr: 20,700
• Max. Heating Capacity 5°F Btu/hr: 16,400
• Max. Heating Capacity -4°F Btu/hr: 13,800
• Rated Power Input W: 2,400
• HSPF: 9.0

Outdoor Unit:

• Maximum Fuse Size A: 25
• Minimum Circuit Amp A: 19
• Outdoor Noise Level dB: 53
• Height: 30"
• Width: 36 3/16"
• Depth: 15 1/8"

Operating Range:

• Cooling °F: 14~115°F
• Heating °F: -4~75°F

Refrigerate Line:

• Connections: Flare
• Liquid O.D. in: 1/4
• Suction O.D. in: 1/2
• Factory Charge Oz: 67.0
• Maximum Line Length Ft / m: 83/25
• Maximum Height Ft / m: 50/15
