Spec Sheet

The VLO 2700K 12V LED Mini Wall Wash fixture in Architectural Bronze is equipped with the Lumen Effect System allows you to switch between four lumen outputs: 150, 300, 450 or 600 easily with the use of the Magnetic Key.

• Equipped with four-lumen levels in one fixture for quick and easy adjustment during or after installation with the Lumen Effect System.
• NEMA 6x5 beam spread from the custom reflector produces clean uniform light distribution, even when installed close to the application. The recessed LED and integrated cowl offer advanced glare control.
• Sealed and fully encapsulated to safeguard from water ingression and the outdoor elements –helping to extend the life of the product
• This VLO Mini Wall Wash light can be utilized on residential properties as either a soft wall wash or a high output floodlight. This fixture can be tucked into more spots allowing it to integrate into the property and landscape easily.
• 4,000-volt system surge protection protects against power surges and irregularities when paired with one of our transformers.
• More robust angle adjustment on knuckle range with a 115-degree vertical rotation.
• Tempered, shock resistance glass with a high tolerance for thermal expansion and stress.
• Perfect for lighting up small wide trees, bushes, and scrubs or illuminating open/wide walls such as retaining walls, fences, and environmental structures (rocks walls or tree lines.)
• IP66 rated
• What's in the box? Includes 8" Slotted In-ground Stake, 2 Gel-Filled Wire Nuts, and Magnetic Key

Dimensions:

• Height: 5.25"

• Length: 4.25"
• Width: 2.25"


Electrical:

• Operating Voltage Range: 9-15 VAC

• Voltage: 12V

Housing:

• Primary Material: Aluminum
• Finish: Textured Architectural Bronze

Light Source:

• Delivered Lumens: 600
• Expected Life Span (Hours): 50,000

• Lamp Included: Integrated

• Light Source: LED

Mounting/Installation:

• Location Rating: Wet

Photometrics:

• Color Rendering Index: 80

• Kelvin Temperature: 2700K
