K-Rain - 6402 - 6000 Series Valve, 4 Outlet, Cammed for 2 Zones
Spec Sheet Install Manual
K-RAIN MODEL 6000: DISTRIBUTING VALVE
The 6000 line of distributing valves offers exceptional reliability and durability even under the dirtiest water conditions.
With a metal die-cast body, the 6000 valves are capable of high pressure applications and are recommended to be used on pump fed systems or high-flow city water systems. The 6000 is also ideal for onsite wastewater and effluent water applications
The 6000 valve is available in 4 or 6 outlet models that are cammed for 2 to 6 zone operation. With only one moving part (the stem and disc assembly), the valve is easily serviced and maintained.
The valve requires 15 GPM to operate and works at pressures from 25 to 150 PSI.
The distributing valve shall carry a two-year trade warranty against manufacturing defects
SPECIFICATIONS
Construction:
Valve Top/Housing: Die Cast Metal Valve Outlets: High Strength ABS Polymer
Flow Range: 15-150 GPM
Pressure Rating: 25 - 150 PSI
Pressure Loss:
4 Outlet Valve Flow (GPM) 20 40 60 80 100 PSI Loss 2.5 3.5 5.0 7.5 10.0
6 Outlet Valve Flow (GPM) 20 40 60 80 100 PSI Loss 3.0 4.0 6.0 9.0 11.0
Inlet: Threaded 1-1/2" NPT Connection
Outlets: Slip and Glue Connections to 1-1/2" PVC Pipe
Built-in Atmospheric Vacuum Breaker
Dimensions: Height: 7" Width: 8"
Product Information
Product Information
Shipping & Returns
Shipping & Returns
K-Rain - 6402 - 6000 Series Valve, 4 Outlet, Cammed for 2 Zones
K-Rain - 6402 - 6000 Series Valve, 4 Outlet, Cammed for 2 Zones
Spec Sheet Install Manual
K-RAIN MODEL 6000: DISTRIBUTING VALVE
The 6000 line of distributing valves offers exceptional reliability and durability even under the dirtiest water conditions.
With a metal die-cast body, the 6000 valves are capable of high pressure applications and are recommended to be used on pump fed systems or high-flow city water systems. The 6000 is also ideal for onsite wastewater and effluent water applications
The 6000 valve is available in 4 or 6 outlet models that are cammed for 2 to 6 zone operation. With only one moving part (the stem and disc assembly), the valve is easily serviced and maintained.
The valve requires 15 GPM to operate and works at pressures from 25 to 150 PSI.
The distributing valve shall carry a two-year trade warranty against manufacturing defects
SPECIFICATIONS
Construction:
Valve Top/Housing: Die Cast Metal Valve Outlets: High Strength ABS Polymer
Flow Range: 15-150 GPM
Pressure Rating: 25 - 150 PSI
Pressure Loss:
4 Outlet Valve Flow (GPM) 20 40 60 80 100 PSI Loss 2.5 3.5 5.0 7.5 10.0
6 Outlet Valve Flow (GPM) 20 40 60 80 100 PSI Loss 3.0 4.0 6.0 9.0 11.0
Inlet: Threaded 1-1/2" NPT Connection
Outlets: Slip and Glue Connections to 1-1/2" PVC Pipe
Built-in Atmospheric Vacuum Breaker
Dimensions: Height: 7" Width: 8"
